Micro Rotary Encoder - 16-Bit Resolution & Ultra-Thin Design

VLP-13

The Netzer VLP-13 Absolute Rotary Encoder is the smallest member of the VLP series, crafted to meet the rising demand for ultra-compact, high-performance motion control solutions. With up to 16-bit resolution and 0.15 Degree accuracy, this ultra-miniature (<7 mm thin, <2g) encoder ensures precise, contactless capacitive sensing for long-term, wear-free reliability in the most space-constrained applications.

As industries strive for smaller, lighter, and more efficient designs, the VLP-13 meets the challenge head-on. Ideal for aerospace, robotics, medical devices, and advanced automation, low-inertia structure enables seamless integration without compromising precision. When miniaturization meets accuracy, the VLP-13 delivers the ultimate rotary feedback solution.

Talk to Expert

Download Assets

Features

Maximum Precision Packed into the Smallest Form Factor Achieves exceptional accuracy and reliable position feedback — all within the most compact encoder design on the market.
Superior Immunity to Electromagnetic and Radio Frequency Interference Robust performance against EMI, RFI, and magnetic fields, ensuring signal integrity even in challenging environments.
Ultra-Lightweight, Compact Absolute Encoder Ideal for weight-critical and space-limited applications, delivering high performance without added bulk.
Innovative Central Aperture for Seamless Mechanical Integration Designed with an open-center structure to simplify installation on shafts or assemblies, offering maximum design flexibility.
Ultra-Low Profile (<7 mm) for Space-Saving System Design Engineered for applications where every millimeter matters, supporting next-generation miniaturized solutions.
Designed Long-Term Reliability with MTBF Exceeding 15 Years Built for endurance, reducing maintenance and ensuring consistent operation over extended service life.for extended service life and minimal maintenance

Unique Values

Small Size
Wide mounting
High precision
Scaled Precision

OD

13.5 mm
Height

7 mm
Weight

2 gr
Resolution

15-19 bit
Accuracy

±0.15˚

Technical Data

Technical Drawing

Download Assets

Ordering Code

General

Angular resolution 15-19 bit
Nominal position accuracy ±0.15°
Maximum operational speed 6,000 rpm
Measurement range Single Turn Absolute with optional shaft turn counter
Built In Test BIT Optional
Rotation direction Adjustable CW/CCW (Default same direction from bottom side of the encoder)

Mechanical

Allowable mounting eccentricity ±0.1 mm
Allowable axial mounting tolerance ±0.15 mm / ±0.2 mm using auto calibration
Rotor inertia 15.56 gr · mm²
Total weight 2 gr (including 250mm cable)
Outer Ø /Inner Ø / Height 13.5/ 0 / 7 mm
Nominal air gap (stator, rotor) 0.4 mm
Material (stator / rotor) FR4

Electrical

Supply voltage 5V ±5%
Current consumption ~110 mA
Interconnection Cable (standard 250mm)
Communication SSi / BiSS-C
Output code Binary
Serial output Differential RS-422
Clock frequency 0.1- 5.0 MHz
Position update rate 35 kHz (Optional - up to 375 kHz)

Environmental

EMC IEC 6100-6-2, IEC 6100-6-4
Operating temperature range -40°C to +105°C
Storage temperature -55°C to +125°C
Relative humidity 98% Non condensing
Shock endurance / functional 100g 6msec saw-tooth per IEC 60068-2-27:2009 40g 11msec saw-tooth per MIL-810G
Vibration functional 7.7grms @ 20 to 2000 Hz per MIL-810G Category 24
Protection IP 40

Create Your Ordering code

OD
- 13.5 mm (ID - )
- 25 mm (ID - 2.2 mm)
- 35 mm (ID - 11 mm)
- 60 mm (ID - 25 mm)
- 80 mm (ID - 35 mm)
- 100 mm (ID - 48 mm)
- 140 mm (ID - 90 mm)
- 170 mm (ID - 110 mm)
- 247 mm (ID - 171 mm)
Communication
- BiSS
- SSi
Resolution
- 14 bit
- 15 bit
- 17 bit
- 18 bit
- 19 bit
- 20 bit
- 21 bit
- 22 bit
- 23 bit
BIT
- Disabled
- Enabled
Shaft-turn Counter
- 2,048
- 4,096
- 8,192
- 16,384
- 32,768
- None
Cable Type
- Jacket and shielded cable
- Shielded cable
- Wires only
- ESA Space Cable
Cable Length
- 250 mm Flying leads - 30AWG
- 500 mm Flying leads - 30AWG
- 750 mm Flying leads - 30AWG
- 1000 mm Flying leads - 30AWG
- 250 mm Flying leads - 28AWG
- 500 mm Flying leads - 28AWG
- 750 mm Flying leads - 28AWG
- 1000 mm Flying leads - 28AWG
Rotor Type
- Hollow Shaft Encoder
- End Shaft - Single Screw- VL35
- End Shaft - Single Screw VL25
- Shaft with Insert
Coating
- Standard Conformal
- Parylene
