EVL - Engineered for Early Design Implementation

Precision with Flexibility, Engineered for Early Design Implementation

Designing mechanical systems with integrated controls requires precise and adaptable feedback solutions, especially during prototyping. That’s why we developed the EVL Evaluation Encoder: a configurable tool that puts you in control of key encoder parameters from day one.

Fully configurable from your workbench

Resolution - Adjustable Bits per Revolution
Interface - BiSS-C or SSi
Software Multi-Turn Counter
Built-in Test (BIT)

The EVL comes in the standard VL form factor (Ø13–247 mm) and are supplied with a 750 mm cable terminating in a female D-type connector, ready for immediate evaluation.

Encoder Explorer software provides full parameter control, plus

Limits View – to avoid out-of-spec operation
Mapping View – to understand protocol behaviour and system impact

When ordering EKITs, you receive two additional cables and a rotating jig

One with an adapter (Blue box) for connecting to a computer (male D-type to USB)
One with flying leads for connecting to your system (male D-type to flying leads)

By experimenting with different parameter combinations during evaluation, you’ll discover the optimal configuration for your system, resulting in a precise encoder part number you can confidently carry forward to production.
